Kawasaki Teryx 4 800 KRT800 4x4 FI 2016-2020 Service Manual

SuperATV's own retrospective on the Teryx line highlights just how significant the 2016 refresh was across the whole range, base trim included: a different hood, new headlights, and a redesigned front bumper, alongside a new tilt steering column and thicker wheel, plus easier driver's-seat adjustment. Electric Power Steering — previously an upgrade — became standard equipment across the entire lineup that year, meaningfully improving low-speed maneuverability and reducing terrain kickback on every Teryx4, not just the pricier trims.

Power comes from the 783cc liquid-cooled SOHC 90-degree V-twin introduced with the significant 2014 redesign, a stroked evolution of the Brute Force 750's engine breathing through dual 36mm Mikuni EFI throttle bodies with four-valve Hemi heads, delivering a claimed 47 lb-ft of torque at 5,500 rpm. UTV Action Magazine's testing consistently praised the resulting combination of turning prowess and straight-line stability, with engine braking helping set up drifts through corners in 2WD and aiding control on steep descents.

The double-X frame stayed structurally unchanged through this generation, with upswept sides and a 79-degree approach angle delivering genuine ground clearance for technical trail work, backed by Fox Podium 2.0 piggyback shocks offering 8 inches of front and 8.3 inches of rear travel, adjustable for preload and 24-position compression damping. A rear transfer case with revised bevel gears and a multi-disc wet-pack rear brake with center-console manual parking brake round out the drivetrain, alongside a small rear bed with 249 lbs of cargo capacity behind the four stadium-style seats. UTV Action's price comparisons consistently found the base Teryx4 800 genuinely competitive against four-seat rivals from Polaris, Honda, and Yamaha — often several thousand dollars less while matching or beating their core capability. Towing capacity holds at 1,300 lbs, with a 7.9-gallon fuel tank and Kawasaki's three-year factory warranty backing the platform.
