• 2011 Harley Davidson XL883N Sportster Iron Service, Workshop & Repair Manual
  • Text 'INSTANT Download' with a green button on a white background
  • Harley-Davidson Sportster service manual page 2-29 wheel lacing with 40-spoke and 32-spoke single row straight flange hub diagrams, fanning top flange spokes procedures, spoke installation sequence for inner and outer spokes, spoke head seating and hand-tightening, rim offset and wheel truing adjustment, angle flange hub notes and brake side identification
  • Harley-Davidson Sportster service manual page 2-60 rear master cylinder removal and disassembly with yoke, external boot, spring pin, push rod, spring retainer, and inner boot components diagram, yoke holding and shoulder nut removal with adjustable wrench, spring compression procedure with safety warning about eye injury, piston and spring disassembly steps, dust cover and O-ring removal, yoke tightening correct and incorrect method comparison photos
1 4

Dr. E Manuals

Harley Davidson XL883N Sportster Iron 2011 Service Manual

Harley Davidson XL883N Sportster Iron 2011 Service Manual

£11.95 GBP
£11.95 GBP
Sale Sold out
Taxes included. Shipping calculated at checkout.
Manual Type

2011 Harley Davidson XL883N Sportster Iron Service / Repair / Workshop Manual

Instant download after purchase, in PDF form, NOT a physical book.

This manual contains 768 pages in English Language plus a 340 page electronic diagnostic manual, it is the only manual you will require to maintain, repair and service your 2011 Harley Davidson XL883N Sportster Iron.

Sample pages and table of contents can be seen in the third product picture, please make sure you are happy with the quality of the manuals before purchasing.

Features Chapters: maintenance, chassis, engine, fuel system, drive/transmission, electrical, appendix a connector repair, appendix b wiring, appendix c conversions, appendix d compensating sprocket, appendix e glossary

Suits Models from 2011

If you have any issues downloading/accessing your manual, please contact us so we can fix this for you.

View full details

Sportster Iron 883 XL883N (2011): "Minimal Dark Custom Styling to the Edge"

Harley's own line on the Iron 883 is that it pushes minimal Dark Custom styling to the edge, with a V-twin beat and gritty, old-school garage features. It has a black powertrain, chopped fenders, a peanut fuel tank and black 13-spoke cast aluminum wheels, 19 inches at the front and 16 at the rear. The 2011 bike came with new paint schemes, including Chrome Yellow.

Power comes from the air-cooled 883cc Evolution V-twin, with a 76.2mm x 96.8mm bore and stroke and an 8.8-8.9:1 compression ratio, fed by Electronic Sequential Port Fuel Injection. Torque is about 70-73 Nm (roughly 52-54 lb-ft) at 3,750 rpm. The gearbox is a 5-speed with a 34/57 chain primary and belt final drive. The exhaust is a chrome staggered shorty with dual mufflers.

The chassis is a mild-steel tubular frame with a 39mm fork (about 3.6 inches of travel) and coil-over preload-adjustable rear shocks (about 1.6 inches). Brakes are a single front disc (300mm) and a single rear disc (260mm). Harley specifies Michelin Scorcher 31 tires, a 100/90B19 front and a 150/80B16 rear.

Confirmed figures list a 31.1-degree rake with 117mm (4.6 inches) of trail, a 1,510mm wheelbase and 120mm of ground clearance. Unladen seat height is 735mm (28.9 inches). The tank holds 12.5 litres (3.3 gallons) and engine oil capacity is 2.65 litres. Weight is 251 kg (553 lbs) dry and 260 kg (573 lbs) in running order.

This factory service manual covers the procedures, torque specs, and diagrams needed to keep a 2011 Sportster Iron 883 XL883N running the way it was built to.
