Harley Davidson XL1200XS Sportster Forty-Eight Special 2019 Service Manual

Harley Davidson XL1200XS Sportster Forty-Eight Special 2019 Service Manual

£11.95 GBP
£11.95 GBP
Sale Sold out
Taxes included. Shipping calculated at checkout.

2019 Harley Davidson XL1200XS Sportster Forty-Eight Special Service / Repair / Workshop Manual

Instant download after purchase, in PDF form, NOT a physical book.

This manual contains 1734 pages in English Language Including Electronic Diagnostic Manual and Wiring Diagrams, it is the only manual you will require to maintain, repair and service your Harley Davidson XL1200XS Sportster Forty-Eight Special.

Sample pages and table of contents can be seen in the third product picture, please make sure you are happy with the quality of the manuals before purchasing.

Suits Models from 2019

If you have any issues downloading/accessing your manual, please contact us so we can fix this for you.

View full details

Sportster Forty-Eight Special XL1200XS (2019): Rainbow Tank Graphics and Fat Chopper-Style Tires

Harley revealed the Forty-Eight Special and the Iron 1200 together in early 2018. The Forty-Eight Special is the chopper-flavoured one. Its tank carries a rainbow graphic that recalls the Shovelhead Sportster era. It rides on a fat 130/90B16 front tire and a 150/80B16 rear, mounted on black split nine-spoke cast aluminum wheels with machined highlights. The exhaust is black and staggered, with slash-cut mufflers. Colours were Vivid Black, Billiard Red and Stone Washed White Pearl.

Power comes from the air-cooled 1,202cc Evolution V-twin, with a 88.9mm x 96.8mm (3.5 x 3.8-inch) bore and stroke and a 10:1 compression ratio, fed by Electronic Sequential Port Fuel Injection. It makes a claimed 65-67 hp at 6,000 rpm and about 96-99 Nm (about 73 lb-ft) of torque at 3,500 rpm. The gearbox is a 5-speed with a multi-plate clutch running in oil, a 57/38 chain primary and belt final drive. Oil capacity is about 2.6 litres, and fuel economy is rated at about 48 mpg.

Suspension is a telescopic fork up front and twin rear shocks. Brakes are a single front disc with a two-piston caliper and a single rear disc with a one-piston caliper, and ABS was optional.

Confirmed dimensions list a 30.2-degree rake with 5.3 inches (135mm) of trail, a 58.9-inch (1,495mm) wheelbase, an 85.2-inch (2,165mm) length and 4.3 inches (110mm) of ground clearance. Seat height is 26.2 inches laden and 27.8 inches unladen.

This factory service manual covers the procedures, torque specs, and diagrams needed to keep a 2019 Sportster Forty-Eight Special XL1200XS running the way it was built to.
