Harley Davidson XL1200X Sportster Forty-Eight 2019 Service Manual

Harley Davidson XL1200X Sportster Forty-Eight 2019 Service Manual

£11.95 GBP
£11.95 GBP
Sale Sold out
Taxes included. Shipping calculated at checkout.

2019 Harley Davidson XL1200X Sportster Forty-Eight Service / Repair / Workshop Manual

Instant download after purchase, in PDF form, NOT a physical book.

This manual contains 1734 pages in English Language Including Electronic Diagnostic Manual and Wiring Diagrams, it is the only manual you will require to maintain, repair and service your Harley Davidson XL1200X Sportster Forty-Eight.

Sample pages and table of contents can be seen in the third product picture, please make sure you are happy with the quality of the manuals before purchasing.

Suits Models from 2019

If you have any issues downloading/accessing your manual, please contact us so we can fix this for you.

View full details

Sportster Forty-Eight XL1200X (2019): "Stand All the Way Out" with Fat Tires and the Peanut Tank

Harley's own dealer copy for this bike says "stand all the way out": heavy-hitting style with fat tires and an iconic peanut tank, a signature bulldog stance and 1200cc of corner-cranking torque. Reviewers put it more bluntly: look up the word bobber in the dictionary and a picture of the Forty-Eight is likely to come up. The 2019 bike sits on the 2016-generation chassis. It has the 49mm conventional telescopic fork, and the tank holds just 2.1 gallons (7.9 litres), so it's the small-tank Sportster in the 1200 range. The Iron 1200 has 3.3 gallons.

Power comes from the air-cooled 1,202cc Evolution V-twin, with a 88.9mm x 96.8mm (3.5 x 3.8-inch) bore and stroke and a 10:1 compression ratio, fed by Electronic Sequential Port Fuel Injection. It makes about 67 hp at 6,000 rpm and about 96 Nm (roughly 71-73 lb-ft) of torque at 3,500 rpm, and drive goes through a belt final drive. Fuel economy is rated at about 5.2 L/100 km, and top speed is about 170 km/h (105 mph). With the small tank, owners get roughly 150 km (94 miles) per tank.

Suspension is the 49mm telescopic fork up front and twin rear shocks. Confirmed figures list a 1,495mm (58.9-inch) wheelbase and a 710mm (28-inch) seat height. Many surviving bikes have aftermarket changes such as larger tanks, ape bars and aftermarket exhausts, so confirm what a customer's bike actually carries before ordering parts.

This factory service manual covers the procedures, torque specs, and diagrams needed to keep a 2019 Sportster Forty-Eight XL1200X running the way it was built to.
