2019 Harley Davidson XL1200C Sportster Custom Service / Repair / Workshop Manual

Instant download after purchase, in PDF form, NOT a physical book.

This manual contains 1734 pages in English Language Including Electronic Diagnostic Manual and Wiring Diagrams, it is the only manual you will require to maintain, repair and service your Harley Davidson XL1200C Sportster Custom.

Sample pages and table of contents can be seen in the third product picture, please make sure you are happy with the quality of the manuals before purchasing.

Suits Models from 2019

If you have any issues downloading/accessing your manual, please contact us so we can fix this for you.

View full details

Sportster 1200 Custom XL1200C (2019): The Chrome-and-Polish Sportster with the Big Tank

The 1200 Custom is the chrome-trimmed cruiser of the Sportster range. Reviewers describe it as a more rebellious evolution of the earlier XL1200C, with a few polished parts, some chrome and the emblematic 1200 engine. Unlike the peanut-tank Iron and Forty-Eight, it carries the larger 4.5-gallon tank, which gives it the range of the family. The bike was updated for 2019 over the 2018 model, with the long-running Evolution powertrain unchanged.

Power comes from the air-cooled 1,202cc Evolution V-twin, with a 88.9mm x 96.8mm (3.5 x 3.8-inch) bore and stroke and a 10:1 compression ratio, fed by Electronic Sequential Port Fuel Injection. It makes about 67-68 hp and about 96 Nm (roughly 71 lb-ft) of torque, with belt final drive. Fuel economy is rated at about 5.2 L/100 km, with a range of about 327 km (203 miles) from a tank, and indicated top speed is about 175 km/h (109 mph).

Because the Sportster 1200 Custom is a long-running model that owners customize heavily, confirm what the machine in front of you actually carries before ordering parts. Seats, handlebars, wheels and exhausts are common changes.

This factory service manual covers the procedures, torque specs, and diagrams needed to keep a 2019 Sportster 1200 Custom XL1200C running the way it was built to.
