Harley Davidson FXSTD Softail Deuce 2007 Service Manual

Harley said the Softail Deuce remains a styling leader by “getting low and long” for 2007. A lowered rear suspension with new shocks cuts seat height by nearly an inch, and a new extended rider footpeg and brake pedal let the rider stretch out from the low Badlander seat. The chromed FX front end has a chrome laced steel 21-inch wheel and a chrome low-rise, flat-track style handlebar. A 160mm rear tire on a silver solid-disc cast aluminum 17-inch wheel suits the slipped Deuce rear fender, and the stretched fuel tank has a full-length chrome console. The bike came in six solid and four two-tone colours, plus three two-tone custom options. The US price was $17,345 plus $290 destination.

2007 brought the new Twin Cam 96B, a rigid-mounted, counterbalanced, air-cooled 1,584cc V-twin with a 95.3mm bore, a 111.1mm stroke and a 9.2:1 compression ratio. Torque is about 92 lb-ft (124.7 Nm) at 3,000 rpm, and Electronic Sequential Port Fuel Injection is standard. The powertrain is black powder-coated with chrome covers. The new 6-speed Cruise Drive gearbox has a belt final drive, replacing the 5-speed of 2006 and before. Harley lists fuel economy of about 53 mpg on the highway and 34 mpg in the city.

The chassis uses a 41.3mm telescopic fork with “beer can” covers and hidden horizontal rear shocks. Brakes are a single 292mm disc at each end, with a four-piston caliper front and rear, and tires are an MH90-21 front and a 160/70B17 rear. Confirmed figures list a 32-degree rake, 5.0 inches of trail, a 95.4-inch length, a 66.6-inch wheelbase and 4.8 inches of ground clearance. Seat height is about 25 inches, dry weight is about 663 lbs and wet weight about 682 lbs.

This factory service manual covers the procedures, torque specs, and diagrams needed to keep a Softail Deuce FXSTD running the way it was built to.
