Harley Davidson FXSTC Softail Custom 2009 Service Manual

Harley Davidson FXSTC Softail Custom 2009 Service Manual

£11.95 GBP
£11.95 GBP
Sale Sold out
Taxes included. Shipping calculated at checkout.
Manual Type

2009 Harley Davidson FXSTC Softail Custom Service / Repair / Workshop Manual

Instant download after purchase, in PDF form, NOT a physical book.

This manual contains 1099 pages in English Language including electronic diagnostic manual, it is the only manual you will require to maintain, repair and service your Harley Davidson FXSTC Softail Custom 2009.

Sample pages and table of contents can be seen in the third product picture, please make sure you are happy with the quality of the manuals before purchasing.

Features Chapters: maintenance, chassis, engine, fuel system, drive, transmission, electrical, appendix a connector repair, appendix b wiring, appendix c conversions, appendix d glossary, tools, torque values, index

Suits Models from 2009

If you have any issues downloading/accessing your manual, please contact us so we can fix this for you.

View full details

Softail Custom FXSTC (2009): A New Low-Profile Front Fender over a 21-Inch Laced Wheel

The Softail Custom is Harley's laid-back cruiser version of the Softail, with ape-hanger bars, a 21-inch laced front wheel and a bobtail rear fender. The 2009 model is a carryover, with one visible change: a new low-profile front fender that hugs the 21-inch laced wheel. The seat is a tufted king/queen style with chrome buttons that flows into an integrated aluminum one-piece backrest for rider and passenger.

Power comes from the rigid-mounted, counter-balanced Twin Cam 96B, an air-cooled 1,584cc V-twin with pushrod-operated overhead valves and hydraulic self-adjusting lifters. It has a 95.3 x 111.1mm bore and stroke and a 9.2:1 compression ratio, fed by Electronic Sequential Port Fuel Injection. Claimed torque is roughly 117-125 Nm (86-92 lb-ft), depending on the source. The gearbox is a 6-speed Cruise Drive with a 9-plate wet clutch and belt final drive. The engine is black powder-coated with chrome covers, and the exhaust is a chrome staggered shorty with dual mufflers.

The wheels are a chrome-profile laced aluminum 21-inch front and a polished slotted-disc forged aluminum 17-inch rear. Tires are an MH90-21 front and a 200/55R17 rear. Brakes are a single 292mm disc at each wheel, with a four-piston front caliper. The fork is a 41.3mm telescopic with chrome dust covers (5.6 inches of travel), with a hidden horizontal coil-over rear shock (4.3 inches). Equipment also includes a chrome horseshoe oil tank, a chrome bullet headlamp, a nostalgic chrome tank console and forward-mounted rider footpegs. Parts data lists a 133-tooth 20mm drive belt, an RA8HC spark plug and an H30292 oil filter.

Confirmed dimensions list a 94.5-inch length, a 66.9-inch wheelbase, a 32-degree rake with 5.0-5.8 inches of trail (sources differ) and 5.1 inches of ground clearance. Seat height is 26.4 inches laden and 28.3 inches unladen. The tank holds 5 gallons. Weight is 672 lbs as shipped and 703 lbs in running order.

This factory service manual covers the procedures, torque specs, and diagrams needed to keep a 2009 Softail Custom FXSTC running the way it was built to.
