Harley Davidson FXSTC Softail Custom 2007 Service Manual

Harley Davidson FXSTC Softail Custom 2007 Service Manual

£11.95 GBP
£11.95 GBP
Sale Sold out
Taxes included. Shipping calculated at checkout.
Manual Type

2007 Harley Davidson FXSTC Softail Custom Service / Repair / Workshop Manual

Instant download after purchase, in PDF form, NOT a physical book.

This manual contains 652 pages in English Language, it is the only manual you will require to maintain, repair and service your Harley Davidson FXSTC Softail Custom.

Sample pages and table of contents can be seen in the third product picture, please make sure you are happy with the quality of the manuals before purchasing.

Features Chapters: maintenance, chassis, engine, fuel system, electric starter, drive, transmission, electrical, appendix, index

Suits Models from 2007

If you have any issues downloading/accessing your manual, please contact us so we can fix this for you.

View full details

Softail Custom FXSTC (2007): Laid-Back Chopper Style with Ape Hangers, a 200mm Rear Tire and the New Twin Cam 96B

Harley pitched the 2007 Softail Custom as the ultimate ride for those who want to kick back with their feet stretched out, solo or with a passenger, with chopper-inspired style and a two-up seat and backrest. It had a new wide 200mm rear tire under a wide, sculpted bobtail fender, a new chrome button-tufted two-up seat with a chrome backrest, and a new profile ape hanger handlebar on bare-knuckle risers. A traditional Fat Bob tank carries custom silkscreen graphics and a custom-sewn leather strap, and the bike has a new front fork slider cover and chrome bullet headlamp. The wheels are a chrome laced steel 21-inch front and a solid-disc 17-inch rear. Colours included Vivid Black, Black Cherry Pearl/Pewter Pearl, Fire Red Pearl/Black Pearl, Deep Cobalt Pearl/Pewter Pearl, Jake Blue Sunglo/Elwood Blue Sunglo, Burgundy/Crème and Gold Pearl and Dark Green Envy Pearl/Light Green Envy Pearl. The US price was $16,895 plus $290 destination.

The Twin Cam 96B is a rigid-mounted, counterbalanced, air-cooled 1,584cc V-twin with a 95.3mm bore and a 111.3mm stroke and a 9.2:1 compression ratio. The powertrain is chrome-detailed, and Electronic Sequential Port Fuel Injection is standard. Torque is about 123 Nm (about 91 lb-ft) at 3,000 rpm. The new 6-speed Cruise Drive gearbox lets the bike glide down the highway at a more relaxed engine speed than ever, and final drive is by belt. Harley lists fuel economy of about 53 mpg on the highway and 34 mpg in the city.

Confirmed figures list an overall height of about 51.7 inches, a laden seat height of about 26.4 inches and a dry weight of about 672 lbs (305 kg).

This factory service manual covers the procedures, torque specs, and diagrams needed to keep a Softail Custom FXSTC running the way it was built to.
