Harley Davidson FXSTB Softail Night Train 2009 Service Manual

Harley Davidson FXSTB Softail Night Train 2009 Service Manual

£11.95 GBP
£11.95 GBP
Sale Sold out
Taxes included. Shipping calculated at checkout.
Manual Type

2009 Harley Davidson FXSTB Softail Night Train Service / Repair / Workshop Manual

Instant download after purchase, in PDF form, NOT a physical book.

This manual contains 1099 pages in English Language including electronic diagnostic manual, it is the only manual you will require to maintain, repair and service your 2009 Harley Davidson FXSTB Softail Night Train.

Sample pages and table of contents can be seen in the third product picture, please make sure you are happy with the quality of the manuals before purchasing.

Features Chapters: maintenance, chassis, engine, fuel system, drive, transmission, electrical, appendix a connector repair, appendix b wiring, appendix c conversions, appendix d glossary, tools, torque values, index

Suits Models from 2009

If you have any issues downloading/accessing your manual, please contact us so we can fix this for you.

View full details

Softail Night Train FXSTB (2009): A Minimalist, Blacked-Out Softail with a 21-Inch Laced Front Wheel

Harley's own Night Train formula is black-on-black and stripped to the bone, with a more minimalist design and a lighter dry weight than the rest of the Softail line, which suits it to nimble handling. For 2009 it carried over with a new low-profile front fender. The styling is a low-slung Badlander-style seat, a drag-style handlebar on six-inch risers and forward-mounted foot controls. It has a bobtail rear fender, a large 21-inch laced steel front wheel and a black cast-aluminum rear wheel.

Power comes from the rigid-mounted, counter-balanced Twin Cam 96B, an air-cooled 1,584cc V-twin with pushrod-operated overhead valves and hydraulic self-adjusting lifters. It has a 95.3 x 111.1mm bore and stroke and a 9.2:1 compression ratio, fed by Electronic Sequential Port Fuel Injection. Claimed torque is roughly 117-125 Nm (86-92 lb-ft), depending on the source. The gearbox is a 6-speed Cruise Drive with a wet multi-plate clutch, a chain primary and belt final drive. The engine is black powder-coated with wrinkle-black and texture-black covers, and the exhaust is a chrome staggered shorty dual.

The chassis is a mild-steel tubular frame with a 41.3mm telescopic fork with "beer can" covers (5.6 inches of travel) and a hidden horizontal coil-over rear shock (4.3 inches). Brakes are a single 292mm disc at each wheel, with a four-piston front caliper and a two-piston rear. Tires are an MH90-21 front and a 200/55R17 rear. Parts data lists a 133-tooth 20mm drive belt, an RA8HC spark plug, an H30292 oil filter and a YTX20HL-BS battery.

Confirmed dimensions list a 66.9-inch wheelbase, a 94.5-94.9-inch length, a rake of 32-33.5 degrees (sources differ) with 5.0 inches of trail and 5.1 inches of ground clearance. Seat height is 25.2 inches laden and 26.8 inches unladen. The tank holds 5 gallons, and weight is 656 lbs dry and about 682 lbs wet.

This factory service manual covers the procedures, torque specs, and diagrams needed to keep a 2009 Softail Night Train FXSTB running the way it was built to.
