Dr. E Manuals

Harley Davidson FXSB Softail Breakout 2017 Service Manual

Harley Davidson FXSB Softail Breakout 2017 Service Manual

£11.95 GBP
£11.95 GBP
Sale Sold out
Taxes included. Shipping calculated at checkout.
Manual Type

2017 Harley Davidson FXSB Softail Breakout Service / Repair / Workshop Manual

Instant download after purchase, in PDF form, NOT a physical book.

This manual contains 604 pages in English Language, it is the only manual you will require to maintain, repair and service your Harley Davidson FXSB Softail Breakout.

Sample pages and table of contents can be seen in the third product picture, please make sure you are happy with the quality of the manuals before purchasing.

Suits Models from 2017

If you have any issues downloading/accessing your manual, please contact us so we can fix this for you.

View full details

Softail Breakout FXSB (2017): "Serious About Its Straight Line Intentions" — And the Genuine Last Year Before the Model Went on Hiatus

Ultimate Motorcycling's own review confirms exactly what defines this bike's stance: "with the beefy 49mm forks kicked out at a 37-degree angle, a 21-inch wheel up front, a fat 240 rear tire, and limited cornering clearance, the 2017 Harley-Davidson Softail Breakout is serious about its straight line intentions. With a High Output Twin Cam 103B motor, the Breakout is a credible muscle bike on city streets."

Power comes from the High Output Twin Cam 103B, a 1,690cc (103.13 cu.in) air-cooled V-twin, delivering a claimed 99.6 lb-ft of torque, run through a 6-speed transmission with belt final drive. Dennis Kirk's own confirmed spec sheet lists a 240/40VR-18 rear tire and 130/60HB-21 front tire, a 49mm fork, and a 132-tooth, 24mm-wide drive belt.

Ultimate Motorcycling's own review confirms genuine muscle-bike styling throughout: drag bars, forward controls, and chopped fenders "add to the purposeful appearance," while Harley still made accommodations for a passenger despite the aggressive stance. Patriot Harley's own confirmed dimensions list a 95.7-inch length, 679 lbs dry weight, and a 5.0-gallon fuel tank.

This exact 2017 model year represents the final year of this Twin Cam-powered generation on the old dual-shock Softail platform — the Breakout was discontinued for 2018 and 2019 before returning as the reworked FXBR, built on Harley's redesigned single-shock Softail chassis with the Milwaukee-Eight 107/114 engine.

This factory service manual covers the procedures, torque specs, and diagrams needed to keep a 2017 Softail Breakout FXSB running the way it was built to.
