Harley Davidson FXSB Softail Breakout 2014 Service Manual

Harley Davidson FXSB Softail Breakout 2014 Service Manual

£11.95 GBP
£11.95 GBP
Sale Sold out
Taxes included. Shipping calculated at checkout.
Manual Type

2014 Harley Davidson FXSB Softail Breakout Service / Repair / Workshop Manual

Instant download after purchase, in PDF form, NOT a physical book.

This manual contains 1169 pages in English Language including the Electrical Diagnostic Manual, it is the only manual you will require to maintain, repair and service your 2014 Harley Davidson FXSB Softail Breakout.

Sample pages and table of contents can be seen in the third product picture, please make sure you are happy with the quality of the manuals before purchasing.

Suits Models from 2014

If you have any issues downloading/accessing your manual, please contact us so we can fix this for you.

View full details

Softail Breakout FXSB (2014): The Fat-Rear-Tire Chopper with Chopped Fenders and Drag Bars

The Breakout is Harley’s factory chopper-style Softail. The look is built on a massive 18-inch, 240mm rear tire, visually balanced by thick forks and chopped fenders, with a shaved tank console and drag handlebar to keep the profile low. The Twin Cam 103B powertrain has a black powder-coat finish with chrome covers, and the bike has a gloss black single-rib cast aluminum oil tank, a 1.25-inch gloss black drag-style handlebar on a pull-back riser, a four-inch riser-mounted speedometer and glass-filled fuel tank medallions. The 2014 US MSRP was $18,499.

Power comes from the rigid-mounted, counterbalanced Twin Cam 103B, an air-cooled 1,690cc V-twin with a 98.4mm x 111.1mm bore and stroke and a 9.6:1 compression ratio, fed by Electronic Sequential Port Fuel Injection. Torque is about 99.5 lb-ft (134 Nm) at 3,000 rpm. The gearbox is a 6-speed with a chain primary (34/46 ratio) and belt final drive.

The chassis is a mild-steel tubular frame with a 41.3mm telescopic fork (143mm of travel) and hidden, horizontal coil-over rear shocks (91mm of travel). Brakes are a single 292mm disc at each end, with a four-piston caliper at the front and a two-piston caliper at the rear. Tires are a 130/60B21 front and a 240/40R18 rear. Geometry is a 35-degree rake with 145mm (5.7 inches) of trail.

Confirmed figures list a 2,445mm (96.3-inch) length, a 1,710mm (67.3-inch) wheelbase and 120mm of ground clearance. Seat height is 24 inches laden and 26.1 inches unladen. Dry weight is about 294 kg (648 lbs), or about 306 kg wet, and the tank holds 5 gallons.

This factory service manual covers the procedures, torque specs, and diagrams needed to keep a Softail Breakout FXSB running the way it was built to.
