Harley Davidson FXSB Softail Breakout 2013 Service Manual

Harley Davidson FXSB Softail Breakout 2013 Service Manual

£11.95 GBP
£11.95 GBP
Sale Sold out
Taxes included. Shipping calculated at checkout.
Manual Type

2013 Harley Davidson FXSB Softail Breakout Service / Repair / Workshop Manual

Instant download after purchase, in PDF form, NOT a physical book.

This manual contains 1524 total pages in English Language including a service manual and electrical diagnostic manual, it is the only manual you will require to maintain, repair and service your Harley Davidson FXSB Softail Breakout.

Sample pages and table of contents can be seen in the third product picture, please make sure you are happy with the quality of the manuals before purchasing.

Suits Models from 2013

If you have any issues downloading/accessing your manual, please contact us so we can fix this for you.

View full details

Softail Breakout FXSB (2013): "The Brooding Younger Brother of Last Year's CVO Breakout" — And the Genuine Launch Year Itself

The FXSB Breakout debuted in 2013 as the regular-production version of a design Harley had already tested a year earlier on the pricier CVO Breakout — Kirk Rasmussen, Harley's Styling Manager at the time, explained the philosophy directly: "we begin by stripping the bike down to the bones and building up from there." Motorcycle.com's own launch review captured the value proposition bluntly: where the CVO version launched "awash in chrome and sparkle" at $26,499, this genuine production model arrived stripped-down and no-BS at $17,899.

Power comes from the Twin Cam 103, an air-cooled V-twin displacing 1,690cc (103.1 cu in), pushrod-operated overhead valves with hydraulic self-adjusting lifters, delivering a claimed 95.5 lb-ft (129.5 Nm) of torque at 3,000 rpm through a 6-speed Cruise Drive transmission with belt final drive. This is the genuine launch-year configuration of the FXSB — worth knowing that ABS was optional on this exact 2013 model, only becoming standard equipment the following year in 2014.

Design cues drew directly from 1950s and 60s Gasser drag-racing culture: alternating-spoke "Gasser" wheels in Vivid Black and machined finish, a massive 240mm rear tire (the widest ever fitted to a production Harley at the time), fenders chopped to the legal limit, and exclusive drag-style handlebars set low and wide for an aggressive, lean-forward riding position. Confirmed dimensions list a 96.3-inch overall length, 67.3-inch wheelbase, a 5-gallon fuel tank, and a genuine 648 lb (294kg) weight, with a four-piston single-caliper front brake and two-piston floating rear.

This exact 2013 launch specification opened a five-year Twin Cam production run for the FXSB, which continued through 2017 before Harley's 2018 Softail platform redesign replaced it with the Milwaukee-Eight-powered FXBR.

This factory service manual covers the procedures, torque specs, and diagrams needed to keep a 2013 Softail Breakout FXSB running the way it was built to.
