Dr. E Manuals
Harley Davidson FLTRX Road Glide 2018 Service Manual
Harley Davidson FLTRX Road Glide 2018 Service Manual
Couldn't load pickup availability
2018 Harley Davidson FLTRX Road Glide Service / Repair / Workshop Manual
Instant download after purchase, in PDF form, NOT a physical book.
This manual contains 2530 pages in English Language, it is the only manual you will require to maintain, repair and service your Harley Davidson FLTRX Road Glide.
Sample pages and table of contents can be seen in the third product picture, please make sure you are happy with the quality of the manuals before purchasing.
Features Chapters: foreword, safety, maintenance, chassis, engine, fuel system, cooling system, drive, transmission, electrical, wiring, reference
Suits Models from 2018
If you have any issues downloading/accessing your manual, please contact us so we can fix this for you.
Share
Road Glide FLTRX (2018): The Sharknose Bagger on the Milwaukee-Eight 107
Harley’s tagline for the Road Glide is “often imitated, but never equaled.” The base Road Glide has been in the touring line since 2010, and it has the distinctive frame-mounted shark-nose fairing, the Milwaukee-Eight 107, easily adjustable emulsion rear shocks, responsive front suspension and Reflex linked Brembo brakes with optional ABS, which electronically link the front and rear brakes. The Boom! Box 4.3 infotainment system (25 watts per channel, 5.25-inch speakers) has Bluetooth and a USB port. The wheels are Enforcer cast aluminum. The 2018 US price was $21,299.
The engine is the Milwaukee-Eight 107, a 1,746cc air/oil-cooled V-twin with pushrod-operated overhead valves, hydraulic self-adjusting lifters and four valves per cylinder. Bore and stroke are 100mm x 111.1mm (3.937 x 4.375 in), with a 10:1 compression ratio and Electronic Sequential Port Fuel Injection. Torque is 111 lb-ft (150 Nm) at 3,250 rpm, power is about 89 hp at 5,450 rpm, and Harley lists fuel economy of about 45 mpg. The exhaust is a chrome 2-1-2 dual system with tapered mufflers. The gearbox is a 6-speed with a 34/46 chain primary drive and belt final drive, with overall ratios of 9.593, 6.65, 4.938, 4.0, 3.407 and 2.875.
The front suspension is a 49mm fork with about 4.6 inches (117mm) of travel. Brakes are dual 300mm front discs and a rear disc with 32mm four-piston fixed calipers, and tires are a Dunlop Multi-Tread 130/60B19 61H at the front and a 180/65B16 81H at the rear. Rake is 26 degrees with 6.8 inches of trail on a 64-inch (1,625mm) wheelbase. The bike is 95.7 inches (2,430mm) long, with 5.5 inches (140mm) of ground clearance. Seat height is 25.9 inches laden and 27.4 inches (695mm) unladen.
The tank holds 6 gallons (22.7 litres), engine oil capacity is 5.2 quarts with the filter, and the saddlebags hold about 2.3 cubic feet. The Road Glide weighs 820 lbs (372 kg) as shipped and 855 lbs (388 kg) in running order.
This factory service manual covers the procedures, torque specs, and diagrams needed to keep a Road Glide FLTRX running the way it was built to.
-
Manual Sourcing
We strive to use freely available sources. Some manuals may be scans or photocopies of older originals. Sample previews are shown on the product page, please review them before purchase to ensure quality meets your needs.
-
