Dr. E Manuals

Harley Davidson FLSTF Softail Fat Boy 2011 Service Manual

Harley Davidson FLSTF Softail Fat Boy 2011 Service Manual

£11.95 GBP
£11.95 GBP
Sale Sold out
Taxes included. Shipping calculated at checkout.
Manual Type

2011 Harley Davidson FLSTF Softail Fat Boy Service / Repair / Workshop Manual

Instant download after purchase, in PDF form, NOT a physical book.

This manual contains 1130 pages in English Language including electrical diagnostics manual, it is the only manual you will require to maintain, repair and service your Harley Davidson FLSTF Softail Fat Boy.

Sample pages and table of contents can be seen in the third product picture, please make sure you are happy with the quality of the manuals before purchasing.

Features Chapters: maintenance, chassis, engine, fuel system, drive, transmission, electrical, appendix a connector repair, appendix b wiring, appendix c abs, appendix d conversions

Suits Models from 2011

If you have any issues downloading/accessing your manual, please contact us so we can fix this for you.

View full details

Softail Fat Boy FLSTF (2011): A Bigger Odometer, a New ABS Option, and a Powerband Ultimate Motorcycling Called "Extremely Wide"

Harley's own description of the Fat Boy hasn't changed much in decades: fat tires, fat bars, a fat fender, and a big black powder-coated, counter-balanced engine. For 2011 the changes were practical. The odometer readout got bigger and showed more information, including gear and RPM, and a new Security Package option added the Anti-lock Braking System and the Smart Security System.

Power comes from the rigid-mounted, counter-balanced Twin Cam 96B, an air-cooled 1,584cc V-twin with pushrod-operated overhead valves, hydraulic self-adjusting lifters, and Electronic Sequential Port Fuel Injection. It uses a 3.75 x 4.38 inch bore and stroke with a 9.2:1 compression ratio and makes a claimed 127 Nm (93.7 lb-ft) of torque at 3,000 rpm. A chain primary drive (34/46 ratio) feeds a 6-speed Cruise Drive transmission with belt final drive, with overall gear ratios running from 9.31 in first to 2.79 in sixth. Ultimate Motorcycling's tester described a very wide powerband, with plenty of torque on tap wherever you are in the rev range, and said the bike responds to the rider "without much thought."

Confirmed figures list a 94.3-inch overall length, a 64.5-inch wheelbase, 5.1 inches of ground clearance, and a 31-degree rake with 5.8 inches of trail. The seat sits just over 25 inches high with a rider aboard, and the front of the seat is cut away so a rider can move their thighs down at a stop. It carries 5 gallons of fuel and 3.5 quarts of oil, and weighs 694 lbs as shipped. US pricing started at $15,999 in Vivid Black.

This 1,584cc Twin Cam 96B configuration ran through 2011. For 2012 Harley moved the Fat Boy to the Twin Cam 103B.

This factory service manual covers the procedures, torque specs, and diagrams needed to keep a 2011 Softail Fat Boy FLSTF running the way it was built to.
