Harley Davidson FLHX Street Glide 2023 Service Manual

Harley Davidson FLHX Street Glide 2023 Service Manual

£11.95 GBP
£11.95 GBP
Sale Sold out
Taxes included. Shipping calculated at checkout.
Manual Type

2023 Harley Davidson FLHX Street Glide Service / Repair / Workshop Manual

Instant download after purchase, in PDF form, NOT a physical book.

This manual contains 686 pages in English Language, it is the only manual you will require to maintain, repair and service your 2023 Harley Davidson FLHX Street Glide.

Sample pages and table of contents can be seen in the third product picture, please make sure you are happy with the quality of the manuals before purchasing.

Features Chapters: safety, maintenance, chassis, engine, drive and transmission, fuel and exhaust, cooling system, electrical, appendix a.1 reference, tools, torque values, index, wiring diagrams

Suits Models from 2023

If you have any issues downloading/accessing your manual, please contact us so we can fix this for you.

View full details

Street Glide FLHX (2023): The Last Year of the Previous-Generation Street Glide

The Street Glide is Harley’s best-known bagger, with a fork-mounted Batwing fairing, a relaxed riding position, stretched saddlebags and an infotainment system. 2023 was the last year of the previous generation. For 2024 Harley redesigned it with the Milwaukee-Eight 117, new fairing bodywork and a 12.3-inch Skyline touchscreen.

Power comes from the Milwaukee-Eight 107, an air-cooled 1,746cc V-twin with pushrod-operated overhead valves and four valves per cylinder. Output is about 86 hp and about 109 lb-ft of torque. Drive is by a 6-speed transmission and belt, and the throttle is fly-by-wire. The higher-spec Street Glide Special carried the Milwaukee-Eight 114.

Harley’s own 2023 figures list a 96.5-inch length, a 37.8-inch width, a 53.1-inch height and a 64-inch wheelbase. Seat height is 26.1 inches laden and 27.4 inches unladen, with 5.3 inches of ground clearance, 26 degrees of rake and 6.7 inches of trail. Tires are Dunlop Harley-Davidson Series, a D408F 130/60B19 front and a D407T 180/55B18 rear.

The tank holds 6 gallons (22.7 litres) with a 1-gallon reserve. Oil capacity is 5.2 quarts with the filter, and the primary chaincase holds 1.1 quarts. Weight is 796 lbs as shipped and 829 lbs in running order, with a gross vehicle weight rating of 1,360 lbs. Luggage capacity is 2.3 cubic feet.

This factory service manual covers the procedures, torque specs, and diagrams needed to keep a 2023 Street Glide FLHX running the way it was built to.
