Harley Davidson FLHTK Electra Glide Ultra Limited 2019 Service Manual
Harley Davidson FLHTK Electra Glide Ultra Limited 2019 Service Manual
Couldn't load pickup availability
2019 Harley Davidson FLHTK Electra Glide Ultra Limited Service / Repair / Workshop Manual
Instant download after purchase, in PDF form, NOT a physical book.
This manual contains 1486 pages in English Language, it is the only manual you will require to maintain, repair and service your Harley Davidson FLHTK Electra Glide Ultra Limited.
Sample pages and table of contents can be seen in the third product picture, please make sure you are happy with the quality of the manuals before purchasing.
Suits Models from 2019
If you have any issues downloading/accessing your manual, please contact us so we can fix this for you.
Share
Electra Glide Ultra Limited FLHTK (2019): The Loaded Batwing Tourer with the New Twin-Cooled Milwaukee-Eight 114
Harley’s tagline for the 2019 Ultra Limited is “experience a ride that is anything but standard,” and “for riders who want it all.” It’s loaded, from the new Twin-Cooled Milwaukee-Eight 114 down to the heated hand grips (six settings). It has the classic Batwing fairing with a splitstream air vent that opens and closes with one touch of a button, the all-new Boom! Box GTS infotainment system (a 6.5-inch edge-to-edge glass touchscreen), electronic cruise control, Reflex linked Brembo brakes with ABS, responsive front and rear suspension and a Tour-Pak carrier with room for two full-face helmets. The 2019 US price was $28,089 plus $435 destination.
The engine is the Twin-Cooled Milwaukee-Eight 114, a 1,868cc V-twin with liquid-cooled cylinder heads, four valves per cylinder, a 102.1mm bore, a 114.3mm stroke and a 10.5:1 compression ratio. Electronic Sequential Port Fuel Injection feeds it. Torque is 122 lb-ft (165 Nm) at 3,000 rpm, power is about 90 hp at 5,450 rpm, and Harley lists fuel economy of about 43 mpg. The gearbox is a 6-speed Cruise Drive with a multi-plate wet clutch and belt final drive.
The chassis has a 26-degree rake with 6.7 inches (170mm) of trail on a 64-inch (1,625mm) wheelbase. Brakes are dual front discs and a rear disc with four-piston fixed calipers, and tires are a Dunlop Multi-Tread 130/80R17 65H at the front and a 180/65R16 81H at the rear. The Ultra Limited is about 102.4 inches (2,600mm) long and 37.8 inches (960mm) wide, with a height of about 56.7 inches (1,440mm). Seat height is 27.5 inches laden and 29.1 inches (740mm) unladen.
The tank holds 6 gallons (22.7 litres), and the Tour-Pak and saddlebags hold about 4.7 cubic feet. The Ultra Limited weighs about 877 lbs (398 kg) as shipped and about 910 lbs (413 kg) in running order, with a gross vehicle weight rating of 1,360 lbs.
This factory service manual covers the procedures, torque specs, and diagrams needed to keep an Electra Glide Ultra Limited FLHTK running the way it was built to.
-
