Harley Davidson FLHTCUI Electra Glide Ultra Classic 2003 Service Manual

Harley Davidson FLHTCUI Electra Glide Ultra Classic 2003 Service Manual

£11.95 GBP
£11.95 GBP
Sale Sold out
Taxes included. Shipping calculated at checkout.
Manual Type

2003 Harley Davidson FLHTCU FLHTCUI Electra Glide Ultra Classic Service Manual

Instant download after purchase, in PDF form, NOT a physical book.

This manual contains 1192 pages in English Language including electrical diagnostics manual, it is the only manual you will require to maintain, repair and service your 2003 Harley Davidson FLHTCU FLHTCUI Electra Glide Ultra Classic.

Sample pages and table of contents can be seen in the third product picture, please make sure you are happy with the quality of the manuals before purchasing.

Features Chapters: maintenance, chassis, engine, fuel system, electric starter, drive, transmission, electrical, fuel injection, appendix a tools, appendix b deutsch electrical connectors, appendix c metric conversions

Suits Models from 2003

If you have any issues downloading/accessing your manual, please contact us so we can fix this for you.

View full details

Electra Glide Ultra Classic FLHTCUI (2003): "There's Never Been a Way to Pack More Motorcycle Between Two Wheels"

Harley's own line on the Ultra Classic is that from front fender to rear luggage, there's never been a way to pack more motorcycle between two wheels. Standard equipment covers just about everything: hard luggage, a big seat, roomy boards, cruise control, a fairing with lowers, and a fuel-injected Twin Cam 88 engine. New for 2003 was a CD player, part of a 40-watt-per-channel AM/FM/weatherband sound system with four low-distortion speakers, electronic passenger controls, and a built-in CB/voice-activated intercom. Buyers could also order full Anniversary dress: two-tone paint, gold cast wheels, engine covers and a seat emblem, to mark the company's 100th year.

Power comes from the air-cooled Twin Cam 88, a 1,449cc V-twin with a 95.3 x 101.6mm bore and stroke and an 8.9:1 compression ratio, making a claimed 67 hp at 5,200 rpm and 110 Nm (81.1 lb-ft) of torque at 3,100 rpm through a 5-speed transmission with belt final drive. Autoevolution's spec sheet for this generation lists a bat-wing fairing with windscreen, a sculpted dual seat with lumbar support, cast-aluminium wheels and full fenders.

Confirmed figures list a 98.3-inch overall length, a 27.2-inch seat height, a 63.5-inch wheelbase, 130/90-16 tires at both ends, dual 292mm front discs with four-piston calipers and a single 292mm rear disc, an 18.9-litre fuel tank with a 1.9-litre reserve, and a dry weight of about 789 lbs.

This factory service manual covers the procedures, torque specs, and diagrams needed to keep a 2003 Electra Glide Ultra Classic FLHTCUI running the way it was built to.
