Harley Davidson FLHTCU Electra Glide Ultra Classic 2014 Service Manual

Harley's own copy pulled no punches launching this bike: "when you set out to improve the most respected touring machine on earth, you don't take short cuts and you sure as hell don't accept any limits." Marking the company's 111th year in business, Harley rolled out more new models in 2014 than any year in its history, driven by Project Rushmore, a ground-up effort to revolutionize the touring experience built on feedback from thousands of real-rider road tests.

Power comes from the air-cooled High Output Twin Cam 103, a V-twin delivering a claimed 104 lb-ft of torque at 3,250 rpm through a 6-speed Cruise Drive transmission, feeding a single-spar rigid backbone frame with a stout swingarm developed specifically for the demands of long-haul touring and more powerful engines. A restyled Batwing fairing with a Splitstream vent reduces head buffeting.

Standard Rushmore-era equipment includes Reflex Linked Brakes with ABS, dual halogen and LED headlamps and fog lamps, a stiffer steering head and front forks, and the new Boom! Box 4.3 audio system with Bluetooth, a 25-watt-per-channel amplifier, four speakers, and a Jukebox media compartment with USB connection — a genuine 25% jump in volume over the outgoing sound system. Saddlebags and Tour-Pak luggage now open with one hand and one touch, with more storage space packed in without altering the bike's silhouette.

Confirmed factory dimensions list a 102.4-inch length, a 27.3-inch laden seat height (29.1 inches unladen), 5.3 inches of ground clearance, and a 6.7-inch trail. The revised seating and back rests, plus more legroom and ergonomically designed hand controls, were built specifically to improve passenger comfort on long rides.

This factory service manual covers the procedures, torque specs, and diagrams needed to keep a 2014 Electra Glide Ultra Classic FLHTCU running the way it was built to.
