Dr. E Manuals

Harley Davidson FLHT FLHTI Electra Glide Standard 2003 Service Manual

Harley Davidson FLHT FLHTI Electra Glide Standard 2003 Service Manual

£11.95 GBP
£11.95 GBP
Sale Sold out
Taxes included. Shipping calculated at checkout.
Manual Type

2003 Harley Davidson FLHT FLHTI Electra Glide Standard Service Manual

Instant download after purchase, in PDF form, NOT a physical book.

This manual contains 1192 pages in English Language including electrical diagnostics manual, it is the only manual you will require to maintain, repair and service your 2003 Harley Davidson FLHT FLHTI Electra Glide Standard.

Sample pages and table of contents can be seen in the third product picture, please make sure you are happy with the quality of the manuals before purchasing.

Features Chapters: maintenance, chassis, engine, fuel system, electric starter, drive, transmission, electrical, fuel injection, appendix a tools, appendix b deutsch electrical connectors, appendix c metric conversions

Suits Models from 2003

If you have any issues downloading/accessing your manual, please contact us so we can fix this for you.

View full details

Electra Glide Standard FLHT/FLHTI (2003): The 100th-Anniversary Year, With Fuel Injection Newly Offered on the Standard

Harley describes the Electra Glide Standard as "the Harley touring experience taken down to pure form." 2003 was the company's 100th anniversary, and the Standard carried it with Vivid Black paint, a "100th" tank cloisonné and a model nameplate. It starts with the Twin Cam 88 at center stage. Buyers could choose a traditional carburetor or, new for 2003 on this model, the heat-managed electronic fuel injection Harley had introduced on its other touring bikes the year before. That's why both FLHT and FLHTI appear in the model code this year.

Power comes from the air-cooled, isolation-mounted Twin Cam 88, a 1,449cc V-twin with two valves per cylinder, a 95.3 x 101.6mm bore and stroke, and an 8.9:1 compression ratio. It makes a claimed 67 hp at 5,200 rpm and 110 Nm (81.1 lb-ft) of torque through a 5-speed transmission. The engine is finished in silver.

The touring package is the bat-wing fork-mounted fairing with the speedometer and tachometer, fiberglass saddlebags, a plush touring saddle, and air-adjustable rear suspension. Braking is triple-disc, with dual 292mm four-piston discs up front and a single 292mm disc at the rear. It rolls on 130/90-16 tires at both ends.

Confirmed figures list a 93.7-inch overall length, a 27.3-inch laden seat height (30.7 inches unladen), 5.1 inches of ground clearance, a 26-degree rake with 6.2 inches of trail, and a 63.5-inch wheelbase. The tank holds 18.9 litres including a 1.9-litre reserve, and dry weight is about 344kg (758 lbs).

This factory service manual covers the procedures, torque specs, and diagrams needed to keep a 2003 Electra Glide Standard FLHT/FLHTI running the way it was built to.
