Harley Davidson FLFBS Softail Fat Boy 114 2019 Service Manual

Harley Davidson FLFBS Softail Fat Boy 114 2019 Service Manual

£11.95 GBP
£11.95 GBP
Sale Sold out
Taxes included. Shipping calculated at checkout.
Manual Type

2019 Harley Davidson FLFBS Softail Fat Boy 114 Service / Repair / Workshop Manual

Instant download after purchase, in PDF form, NOT a physical book.

This manual contains 2150 pages in English Language, it is the only manual you will require to maintain, repair and service your Harley Davidson FLFBS Softail Fat Boy 114.

Sample pages and table of contents can be seen in the third product picture, please make sure you are happy with the quality of the manuals before purchasing.

Suits Models from 2019

If you have any issues downloading/accessing your manual, please contact us so we can fix this for you.

View full details

Fat Boy 114 (2019): "The Original Fat Custom Icon," 30 Pounds Lighter

Harley's own copy calls the Fat Boy simply "an icon" — and by 2019, that icon had gone through a genuine diet: 30 lbs lighter than the previous generation thanks to the reinvented Softail platform introduced the year prior. Buyers could choose between a 107 and this range-topping 114, with the bigger engine delivering noticeably stronger low-end torque instantly noticeable off the throttle, per Harley's own marketing.

The Milwaukee-Eight 114 displaces 113.99 cubic inches (1,868cc), run through a 6-speed gearbox with belt final drive. The signature stance stays completely intact: solid disc wheels front and rear, a 160mm front tire and a genuinely massive 240mm rear tire — proportions no other model in Harley's lineup shares. Satin chrome finishes throughout, paired with signature LED lighting, keep the styling faithful to the model's decades-long identity.

Dimensions run 93.3 in. long, with dry weight coming in at 670 lbs and a 5-gallon fuel tank. Front and rear tires run 160/60R-18 and 240/40R-18 respectively, mounted to solid-disc wheels that remain the Fat Boy's most immediately recognizable visual signature.
