Harley Davidson FLFBS ANV Softail Fat Boy 114 Anniversary 2023 Service Manual
Harley Davidson FLFBS ANV Softail Fat Boy 114 Anniversary 2023 Service Manual
Couldn't load pickup availability
2023 Harley Davidson FLFBS ANV Softail Fat Boy 114 Anniversary Service / Repair / Workshop Manual
Instant download after purchase, in PDF form, NOT a physical book.
This manual contains 590 pages in English Language, it is the only manual you will require to maintain, repair and service your Harley Davidson FLFBS ANV Softail Fat Boy 114 Anniversary.
Sample pages and table of contents can be seen in the third product picture, please make sure you are happy with the quality of the manuals before purchasing.
Suits Models from 2023
If you have any issues downloading/accessing your manual, please contact us so we can fix this for you.
Share
FLFBS ANV Fat Boy 114 120th Anniversary (2023): Only 3,000 Built, Wearing a Paint Scheme Terminator 2 Never Saw
TopSpeed's own review credits the Fat Boy's genuine pop-culture legacy — Arnold Schwarzenegger riding a 1991 model into a drainage sluice in Terminator 2 — while confirming this exact commemorative edition adds something new on top of that heritage: a limited run celebrating Harley's 120th anniversary. MotorSportsUniverse's own confirmed production figure lists 3,000 units built in this exact anniversary trim — "almost double the number of Harley's other limited-edition anniversary models" that year.
Power comes from the Milwaukee-Eight 114, a 1,868cc air-cooled V-twin with a 102mm bore and 114.3mm stroke and a 10.5:1 compression ratio, fed by Electronic Sequential Port Fuel Injection through a 2-into-2 staggered exhaust with catalyst-equipped muffler, delivering a genuine 110 mph top speed. TopSpeed's own confirmed pricing lists the standard 2023 update bringing electronic cruise control as standard equipment for the first time — the platform's only mechanical change since its 2021 refresh.
MotorSportsUniverse's own confirmed styling details describe the genuine finish that sets this anniversary edition apart: a Heirloom Red Fade paint scheme with each gleaming panel outlined in a bright-red pinstripe surrounded by a dark Midnight Crimson fade, plus an Art Deco eagle tank medallion and gold-embroidered Harley-Davidson logo. Harley's own confirmed product copy describes the Fat Boy's signature "steamroller stance": solid-disc Lakester wheels wrapped in the widest front tire the factory has ever offered, 160mm up front and 240mm at the rear.
Thunderbike's own confirmed dimensions list an 18.9-litre fuel tank, 675mm unladen seat height, 30-degree rake, and 317kg curb weight in running order, riding on Michelin Scorcher 11 tires front and rear. A high-performance rear monoshock allows adjustable, dynamic cornering while preserving the model's signature hardtail look, backed by signature LED forward lighting. This anniversary edition commanded roughly a $1,500 premium over the standard 2023 Fat Boy 114's $20,199 starting price.
This factory service manual covers the procedures, torque specs, and diagrams needed to keep a 2023 Fat Boy 114 120th Anniversary FLFBS ANV running the way it was built to.
-
