Ducati Multistrada MTS 1200 2015-2017 Service Manual

Autoevolution's own account confirms exactly what this base model represents within the wider 2015-2017 Multistrada 1200 lineup covered across the S, S D|air, Enduro, and Pikes Peak variants: "the Italian motorcycle manufacturer launched the Ducati Multistrada 1200, the base model of the range that came equipped with the latest technology package from the House of Borgo Panigale. It packed the Ducati Safety Pack (DSP) that included Ducati Traction Control (DTC), Bosch Cornering ABS, Ducati Wheelie Control (DWC), cruise control, Ducati Skyhook Suspension (DSS), and a ride-by-wire system that offered four riding modes, Sport, Touring, Urban, and Enduro." Genuinely, this base trim carries the exact same electronics foundation and fundamental engine as its pricier siblings — the real distinctions lie in suspension sophistication and finish level rather than raw capability.

Power comes from the Testastretta DVT, a 1,198.4cc liquid-cooled 90-degree L-twin, DOHC with 4 valves per cylinder and hydraulically-actuated Desmodromic Variable Timing, fed by Bosch electronic fuel injection through elliptical throttle bodies with ride-by-wire, delivering a claimed 160 hp at 9,500 rpm and roughly 100 lb-ft (136 Nm) of torque at 7,500 rpm through a 6-speed transmission with chain final drive. Rider Magazine's own detailed technical account confirms the fundamental variable-valve-timing engineering shared identically across every trim in the range, including this base model: "this Desmodromic Variable Timing, or DVT, uses hydraulic phasers to rotate the camshafts forward or backward independently relative to the crankshaft, adjusting the duration of the valve overlap a total of 90 degrees" — genuinely the same real engineering breakthrough underpinning the S-trim's more celebrated reputation, present unchanged in this less expensive entry point.

MCN's own comparison against the S trim confirms exactly what genuinely differs on this base model: it runs conventional, manually-adjustable suspension rather than the S-trim's semi-active Ducati Skyhook Suspension Evo, standard (rather than Panigale-spec Monobloc) Brembo braking hardware, and a simpler, non-TFT instrument display in place of the S-trim's backlit color panel — real, functional distinctions rather than purely cosmetic ones, though the base model still carries the full Ducati Safety Pack electronics suite and the genuinely important five-axis IMU platform that enables cornering ABS and lean-angle-aware traction control across the whole range.

Total Motorcycle's own account confirms the IMU's fundamental role across every 2015-2017 Multistrada 1200 trim, base model included: "the introduction of the IMU (Inertial Measurement Unit) has reshaped the 4-bikes-in-1 concept that lies at the core of the Multistrada. In addition to allowing implementation of all the electronic strategies already featured on the previous version, the new Multistrada 1200 also introduces Ducati Wheelie Control (DWC) and Cornering ABS." That same source confirms the genuine engine-management philosophy shared throughout the entire range: "on the new Multistrada 1200 engine output is controlled by a Ride By Wire system. Power is not adjusted directly via a throttle cable; instead, throttle body opening is regulated by the engine control unit after it reads and processes the Ride by Wire signal input."

The chassis uses a tubular steel trellis frame with a conventional 48mm fully adjustable inverted fork (manually adjustable rather than electronically controlled) and a fully adjustable rear monoshock, braking through dual front discs with Brembo calipers and a rear disc, both backed by standard cornering ABS. Rider Magazine's own account confirms this base platform's genuine commercial importance to Ducati: following the earlier 2013 refresh that improved touring capability and user-friendliness, "the Multistrada subsequently went on to become the company's bestselling bike" — a real testament to how well this fundamental, accessible entry point into the DVT-engine Multistrada family performed in the market. This exact 2015-2017 configuration represented the genuine baseline before Ducati's larger-displacement 1260 platform replaced this entire architecture starting in 2018.

This factory service manual covers the procedures, torque specs, and diagrams needed to keep a 2015-2017 Multistrada 1200 running the way it was built to.
