Harley Davidson FXFBS Softail Fat Bob 114 2021 Service Manual

Harley Davidson FXFBS Softail Fat Bob 114 2021 Service Manual

£11.95 GBP
£11.95 GBP
Sale Sold out
Taxes included. Shipping calculated at checkout.
Manual Type

2021 Harley Davidson FXFBS Softail Fat Bob 114 Service / Repair / Workshop Manual

Instant download after purchase, in PDF form, NOT a physical book.

This manual contains 1096 pages in English Language and includes the full electrical diagnostic manual, it is the only manual you will require to maintain, repair and service your Harley Davidson FXFBS Softail Fat Bob 114.

Sample pages and table of contents can be seen in the third product picture, please make sure you are happy with the quality of the manuals before purchasing.

Suits Models from 2021

If you have any issues downloading/accessing your manual, please contact us so we can fix this for you.

View full details

Fat Bob 114: Aggressive Redesign, Muscular Torque, All-Road Attitude

Introduced for 2018 and carried into 2021 with no changes beyond fresh colors, the Fat Bob 114 leans into a deliberately aggressive redesign that broke from Harley's older Fat Bob styling. The most distinctive touch is the split, dual-headlight LED front end, set into an inverted race-style single-cartridge fork wrapped around a fat 150mm front tire — a look nothing else in the Softail range shares.

Power comes from the Milwaukee-Eight 114, putting out a claimed 118 lb-ft of torque through a 6-speed gearbox, running electronic sequential port fuel injection and a 2-into-2 shorty dual exhaust finished in contrasting bronze. Bore and stroke sit at 4.016 in. and 4.5 in., with a 10.5:1 compression ratio. Mantis-style cast aluminum wheels carry a 150/80B16 front and 180/70B16 rear tire, gripped by dual disc brakes designed to handle the extra torque.

Dimensions run 92.1 in. long with a 63.6 in. wheelbase and a 27.7 in. laden seat height — noticeably taller than most Softail cruisers, part of what gives the Fat Bob its more upright, muscular riding stance. Fuel capacity sits at 3.6 gallons, with a shipped weight of 653 lbs. Standard equipment includes ABS, keyless ignition, and a security system, with 2021 pricing starting at $18,799 for Vivid Black.

Whatever the roads look like where a Fat Bob 114 gets ridden, this factory manual covers the torque specs, wiring diagrams, and procedures to keep it running the way it was built to.
