Harley Davidson XL1200C Sportster Custom 2020 Service Manual

Harley Davidson XL1200C Sportster Custom 2020 Service Manual

£11.95 GBP
£11.95 GBP
Sale Sold out
Taxes included. Shipping calculated at checkout.
Manual Type

2020 Harley Davidson XL1200C Sportster Custom Service / Repair / Workshop Manual

Instant download after purchase, in PDF form, NOT a physical book.

This manual contains 613 pages in English Language, it is the only manual you will require to maintain, repair and service your Harley Davidson XL1200C Sportster Custom.

Sample pages and table of contents can be seen in the third product picture, please make sure you are happy with the quality of the manuals before purchasing.

Suits Models from 2020

If you have any issues downloading/accessing your manual, please contact us so we can fix this for you.

View full details

Sportster 1200 Custom XL1200C (2020): The Fat-Front-End Sportster in Its Final Evolution Years

Harley’s 1200 Custom has a fat 16-inch front wheel where a Sportster usually has a skinny 21-inch, with a 130/90B16 tire in place of a 100mm one, giving it a chunkier, more muscular stance than other Sportsters. Its 39mm fork is tilted at 30 degrees, and the bike has a pull-back handlebar, a two-up custom seat and chrome 16 x 3.0-inch spoke wheels front and rear. Reviewers like the agile turn-in despite the big front wheel and criticise the weak front brake. It came in colours such as Midnight Blue, and a 2020 US price of about $11,999 was typical.

Power comes from the air-cooled 1,202cc Evolution V-twin, with Electronic Sequential Port Fuel Injection. The gearbox is a 5-speed with belt final drive. Torque is about 98 Nm (about 72 lb-ft) depending on the source.

Tires are Michelin Scorcher 31, a 130/90B16 front and a 150/80B16 77H rear. Confirmed figures list a dry weight of about 562 lbs (255 kg), with an ABS kerb weight of about 265 kg.

This factory service manual covers the procedures, torque specs, and diagrams needed to keep a Sportster 1200 Custom XL1200C running the way it was built to.
