Harley Davidson XL883L Sportster SuperLow 2019 Service Manual

Harley Davidson XL883L Sportster SuperLow 2019 Service Manual

£11.95 GBP
£11.95 GBP
Sale Sold out
Taxes included. Shipping calculated at checkout.

2019 Harley Davidson XL883L Sportster SuperLow Service / Repair / Workshop Manual

Instant download after purchase, in PDF form, NOT a physical book.

This manual contains 1734 pages in English Language Including Electronic Diagnostic Manual and Wiring Diagrams, it is the only manual you will require to maintain, repair and service your Harley Davidson XL883L Sportster SuperLow.

Sample pages and table of contents can be seen in the third product picture, please make sure you are happy with the quality of the manuals before purchasing.

Suits Models from 2019

If you have any issues downloading/accessing your manual, please contact us so we can fix this for you.

View full details

Sportster SuperLow XL883L (2019): The Lowest, Most Approachable Sportster, in Its Final Evolution-Era Form

The SuperLow is the entry point to the Sportster range, built around a low seat and a relaxed riding position. Harley's own line on it is that its value and quality have no competition in its class. A French test says the name is no coincidence. 2019 replaced the 2018 model, with a modest price rise at launch, and it is still the bike with the Sportster-style full-size tank, with a 4.5-gallon (17-litre) capacity, where the Iron 883 has a 3.3-gallon peanut tank.

Power comes from the air-cooled 883cc Evolution V-twin, with a 76.2mm x 96.8mm (3.0 x 3.8-inch) bore and stroke, fed by Electronic Sequential Port Fuel Injection. It makes about 52-53 hp and about 70-75 Nm (roughly 52-55 lb-ft) of torque. Drive goes through a multi-plate wet clutch, a chain primary and belt final drive. Parts data lists a 29-tooth front and 68-tooth rear pulley, a 1-inch 137-tooth belt and an NGK 6R12 spark plug.

The chassis is a mild-steel tubular frame with a 39mm Showa fork and dual-adjustable rear shocks. Brakes are a single front disc with a two-piston caliper and a single rear disc, with optional ABS. Tires are a 120/70ZR18 front and a 150/60ZR17 rear.

Harley's published dimensions for this chassis have stayed consistent across its run. They list a 2,215mm (87.2-inch) length, a 1,500mm (59-inch) wheelbase, a 695mm (27.4-inch) unladen seat height and 100mm (4 inches) of ground clearance. Dry weight is about 247-251 kg (545-553 lbs). Fuel economy is rated at about 4.8 L/100 km and top speed is about 160 km/h (99 mph).

This factory service manual covers the procedures, torque specs, and diagrams needed to keep a 2019 Sportster SuperLow XL883L running the way it was built to.
