Harley Davidson XL1200R Sportster Roadster 2016 Service Manual

Motorcycle.com's own first-ride review captures the reaction from several journalists at launch bluntly: "some of the attendees at the launch felt that the Roadster was the Sportster that Harley should have built all along." MCN's review frames the achievement in genuinely surprising terms for a Sportster: "a significant chassis makeover with credible performance-orientated suspension, brakes and wheels... has turned it into a genuine café racer that's been a surprising hoot to thrash around twisty roads" — a real departure from the historically un-sporty reputation the Sportster range had carried for decades.

Power comes from the unchanged air-cooled, 1,202cc Evolution 45-degree V-twin shared across the 1200 Sportster family, delivering a claimed 66 hp with torque peaking at 3,750 rpm, run through a 5-speed transmission. Ultimate Motorcycling's own review notes the "brawny torque runs from 2,000 rpm up to the redline of 6,000 rpm... dialing in the right speed requires little effort," with gear shifting almost optional on backroads once up to cruising speed.

What genuinely transforms the platform is the chassis: fat 43mm inverted forks, a bigger 19-inch front and 18-inch rear lightweight alloy wheel combination, and proper, longer rear shocks fundamentally reorient the familiar tubular steel cradle frame's geometry versus a standard 1200 Sportster. Twin front discs with twin four-piston calipers deliver genuinely confident braking, backed by ABS, while a fork angle of 27.4 degrees and 59-plus-inch wheelbase give the bike stability-focused handling that rewards smooth cornering lines over aggressive direction changes. Ultimate Motorcycling's testing found cornering clearance genuinely good at over 30 degrees on both sides — Dunlop tires take riders right to the peg feelers without drama. Harley's Dark Custom styling covers the bike in blacked-out finishes: black engine, black paint, black forks, black exhaust heat guards, and cut-down black mudguards, paired with a "slammed drag-style handlebar," rear-set footpegs, and a race-style solo seat, while an integrated digital speedometer sits within the analog tachometer housing. Curb weight comes in at 586 lbs, with 2016 pricing starting at $11,199.

This factory service manual covers the procedures, torque specs, and diagrams needed to keep a 2016-onward Sportster Roadster XL1200CX running the way it was built to.
