Harley Davidson FLHR FLHRI Road King 2003 Service Manual

Harley Davidson FLHR FLHRI Road King 2003 Service Manual

£11.95 GBP
£11.95 GBP
Sale Sold out
Taxes included. Shipping calculated at checkout.
Manual Type

2003 Harley Davidson FLHR FLHRI Road King Service Manual

Instant download after purchase, in PDF form, NOT a physical book.

This manual contains 1192 pages in English Language including electrical diagnostics manual, it is the only manual you will require to maintain, repair and service your 2003 Harley Davidson FLHR FLHRI Road King.

Sample pages and table of contents can be seen in the third product picture, please make sure you are happy with the quality of the manuals before purchasing.

Features Chapters: maintenance, chassis, engine, fuel system, electric starter, drive, transmission, electrical, fuel injection, appendix a tools, appendix b deutsch electrical connectors, appendix c metric conversions

Suits Models from 2003

If you have any issues downloading/accessing your manual, please contact us so we can fix this for you.

View full details

Road King FLHR/FLHRI (2003): The Base Road King in 100th-Anniversary Dress

Harley's own copy calls out the Road King's heritage-rich styling directly: a large Hiawatha headlight and chrome nacelle, a detachable windshield, a large tank-mounted speedometer, a two-piece seat, and fiberglass saddlebags, all built around the vibration-isolated, black-and-chrome Twin Cam 88 engine. Unlike the pricier Classic trim, the standard Road King was sold with a genuine choice: carburetor as FLHR or Electronic Sequential Port Fuel Injection as FLHRI.

Power comes from the air-cooled Twin Cam 88, a 1,449cc V-twin with a 95.3 x 101.6mm bore and stroke, feeding a 5-speed transmission with belt final drive. Triple-disc brakes and air-adjustable rear touring suspension came standard, and this was Harley's 100th anniversary year, so anniversary paint and badging were available across the range.

Confirmed factory figures list a 93.7-inch overall length, a 27.3-inch laden seat height (29.5 inches unladen), 5.1 inches of ground clearance, a 26-degree rake with 6.2 inches of trail, and a 63.5-inch wheelbase. It rolls on Dunlop Harley-Davidson Series MT90B16 tires at both ends. Fuel capacity is 5.0 gallons including a 1.0-gallon reserve, with the low-fuel warning light triggering at approximately 1.0 gallon remaining on ESPFI models.

Standard extras commonly fitted to this model year include a Smart Security System with a proximity-based, hands-free fob, adjustable passenger floorboards, adjustable highway pegs, a quick-detach windshield with a storage pouch, and a passenger backrest.

This factory service manual covers the procedures, torque specs, and diagrams needed to keep a 2003 Road King FLHR/FLHRI running the way it was built to.
