Harley Davidson FLSTF Softail Fat Boy 1995-1996 Service Manual

By 1995, the Fat Boy needed no introduction. Launched in 1990 and turned into a global icon almost overnight thanks to Arnold Schwarzenegger riding one through Terminator 2, the FLSTF carried that same unmistakable formula into the mid-'90s largely unchanged — solid 16-inch aluminum disc wheels front and rear, a design choice no other Harley model shared, giving it a heavier, more industrial presence than any wire-spoke cruiser in the lineup.

Power comes from the 80-cubic-inch (1,340cc) air-cooled Evolution V-twin, running through a Keihin carburetor and a 5-speed transmission with belt final drive — the same engine platform that carried the Fat Boy from 1990 clear through 1999, a full decade before the Twin Cam took over. 1996 brought Harley's first factory move toward fuel injection across some models, though the carbureted Evo stuck around on the Fat Boy through the rest of the decade, alongside minor cosmetic refinements like updated paint and tank graphics.

The Softail frame hides the rear shocks beneath the transmission, giving the Fat Boy its hardtail look while still riding on real suspension. Dimensions run a 62.5-inch wheelbase and 26.3-inch seat height, with a 5-gallon tank, and the bike tips the scales at a substantial 706-710 lbs — heavy enough to earn its name honestly, whichever origin story you believe.

Thirty-plus years on, these Evo-era Fat Boys are firmly in collector territory. This factory service manual covers the procedures, torque specs, and diagrams needed to keep a 1995-1996 Fat Boy running the way it did the day it left the showroom.
